Dewatering for Basement Construction

Most excavations for basement construction will encounter groundwater. If this groundwater is not suitably controlled, then it can cause problems for excavation and basement construction. These problems include seepages that reduce the efficiency of construction operations, major inflows that can result in instability, flooding and even collapse of the excavation, leading to fatal accidents.

Adequate control of groundwater is therefore important and is a necessary part of a well-planned basement construction project. The site engineer has to take proper steps for dewatering for basement construction. Here we have given brief information on dewatering for basement construction, which a site engineer must know.

Dewatering for Basement Construction

Problems Encountered During Basement Construction

If during basement construction, an excavation is made without suitable groundwater control, then various problems may occur such as:

  • Flooding of the construction area due to water seepage and inflow from the surrounding soil.
  • Instability of excavation side slopes and base due to high water pressure. The excavation may even collapse.
  • Reduced efficiency in construction operation due to obstruction from the seepage.
  • Groundwater can change the course of the entire construction project. However, through dewatering techniques, you can control it and resume normal basement construction.
  • Groundwater uplift pressures below the floor of excavation may give the risk of piping failure in the base of the excavation.

Dewatering methods (also known as groundwater control methods) can be used to control groundwater and avoid these problems. In addition to groundwater, surface water also needs to be controlled. Any excavation should have a system for surface water control, typically consisting of sump pumps and drains. Surface water can come from various sources such as rainfall, seepage from nearby rivers or lakes, leaking sewers and water mains, etc. Thus, surface water must also be controlled for efficient construction without any hindrance.

Also Read: Well Point System: For Foundation in Water-logged Area
Water in Foundation due to Groundwater

Dewatering for Basement Construction

Dewatering for Basement Construction can be classified into two types: by exclusion or by pumping.

01. Basement Dewatering by Exclusion

To avoid the high cost of pumping the water, dewatering can also be done by installing a very low permeability cut-off wall to exclude groundwater from the excavation. If a low permeability stratum exists at shallow depth beneath the excavation then the cut-off wall can penetrate down to that stratum to create a full cut-off.

Several different geotechnical methods can be used to form cut-off walls:

  • Steel sheet piles
  • Concrete secant pile walls
  • Concrete diaphragm walls
  • Slurry walls and trenches
  • Grout curtains (including permeation grouting and jet grouting)
  • Freeze walls (produced by artificial ground freezing)
  • Compressed air (for tunnels and shafts)

Concrete continuous pile walls leave a gap between the piles and do not form an effective cut-off to groundwater flow. Some of the cut-off wall methods are temporary; such as steel sheet-piles, which can sometimes be extracted at the end of the job. These temporary methods should not have a prominent effect on groundwater conditions at the site once the project is completed. However, methods that permanently affect soil permeability or leave a permanent barrier in place can permanently alter groundwater flow at a site. Hence, it is necessary that the potential impact of such problems must be assessed at a design stage.

Even when a cut-off wall is used, some pumping will be required to cope with:

01. Groundwater trapped within the cut-off area

02. Rainfall and precipitation

03. Seepage through the wall and through the ground

Groundwater control by exclusion is widely used in situations when there is a risk of external impacts such as a settlement of nearby structures or detrimental effects on other water users caused by the lowering of the groundwater table. An exclusion system can if carried out effectively and if ground conditions are favourable, minimize any groundwater lowering outside the dewatered site area.

Also Read: Foundation System: All The Basic Things You Need to Know
Basement Dewatering by Exclusion

02. Basement Dewatering by Pumping

Basement dewatering by pumping involves pumping groundwater from an array of wells or sumps with the aim of temporarily lowering groundwater levels to allow excavation to be carried out in dry and stable conditions. The most common types of groundwater control by pumping are as follows:

  • Sump pumping
  • Wellpoint dewatering
  • Shallow suction wells
  • Relief Wells
  • Deep well  dewatering
  • Educator dewatering

On a given site, these dewatering methods are not readily interchangeable. Each method has a relatively narrow range of application, and dependent on two key parameters: the drawdown required and soil permeability.

Basement Dewatering by Pumping

Hence, the aforementioned guidelines can be followed for dewatering of basement construction. The site engineer must make judicial choice of dewatering by examining the site conditions.
