Classification of Aggregates According to Nature of Formation

Gharpedia.com helps to Build/Own/Rent/Buy/Sell/Repair/Maintain your dream house by providing all the tips & tricks in easy languages. It provides solutions to all problems pertaining to houses right from concept to completion and beyond including operation & maintenance, throughout the life of the buildings under one roof. The ultimate goal is the Health, Safety and Happiness of all.

The basic classification of aggregates according to the nature of formation is natural and artificial aggregates which plays the key role in concrete mix design. Natural aggregates are most commonly used in the construction industry till now. But due to industrialization, various by-products are nowadays used as aggregates, which are called artificial aggregates.

0302030003-01-Classification-of-Aggregates-4566256357_147f2cf019_o
Classification of Aggregates
Courtesy - Flickr

Aggregates play the major role to make the main matrix of the concrete. It is a collective term for sand, gravel and crushed stone. It is used with a binding medium such as cement, lime, etc. to form a solid mass of concrete.

Also Read: Know the Role of Aggregates in Concrete

According to the size, the classification of aggregates is fine aggregates and coarse aggregates. According to the shape, classification of aggregate are rounded shaped, irregular or partly rounded shaped, angular shaped, flaky shaped aggregate.

Also Read:

Size Wise Classification of Aggregates
Shape Wise Classification of Aggregates

Here we discuss the classification of aggregates according to the nature of formation.

Classification of Aggregates:

Basically, aggregates can be classified as either natural or artificial aggregates, both of described here.

01. Natural Aggregates:

Aggregates are abundantly available from the natural sources. Natural aggregates are further divided into two categories as below.

(a) Sand and Gravel:

The source of sand and gravel are river beds, stream deposits etc. The aggregates are the results of the weathering of bedrock and subsequent transportation and deposition of the material by water or ice. But nowadays the availability of natural sand is becoming scare in a certain region of the world. Somewhere due to soil erosion, the sand contains a large amount of silt and clay, making it almost unusable. Construction industry needs to solve this challenge by finding suitable alternatives.

0302030003-01-Sand
0302030003-02-Gravel
Sand and Gravel
Courtesy - 123rf

(b) Crushed Aggregates:

Crushed aggregates are the most basic mineral in construction produced from the quarries. It is widely available and inexpensive. Crushed aggregates consist of rock fragments which have been subjected to mechanical processing such as crushing, washing and sizing. They are mainly derived from the parent bed rock material such as igneous rocks, sedimentary rocks and metamorphic rocks.

0302030003-03-Crushed-Aggregates
Crushed Aggregates
Courtesy - 123rf
Also Read: Know Basic Properties and Qualities of Natural Aggregates

02. Artificial Aggregates:

Artificial aggregates are eco-friendly materials. They are made out of various by-products such as fly ash, power plant solid waste, rice husk ash, blast furnace slag, granite powder, iron oreslag, over burnt brickbats etc. As such these materials are considered as pollutants of the environment.

In the present scenario, the challenges before the world are to have innovative materials in the construction industry. On the other hand, there is a huge demand for natural aggregates, on one hand, there is a problem of disposal of such by-products. By using artificial aggregates, we solve the problem of this disposal and at the same time save natural resources. It also creates a problem of depleting natural resources. By using these industrial by-products, we can reduce environmental pollution, dwindling natural resources and thereby giving way to sustainable development of aggregate industries.

Must Read:

What are the Sources of Natural Aggregates?
7 Lab Tests the Aggregate should satisfy for Use in Concrete?
