Classification of Cracks: Nature Wise, Width Wise & Shape Wise

This post is also available in: हिन्दी (Hindi)

An occurrence of the cracks is often a subject that raises numerous questions. Cracks may appear in structures, either at the initial stage or with time. It should first of all be accepted that cracks of some type are unavoidable in any structure.

General Classification of cracks: Structural, nonstructural, thin, medium, wide, straight, toothed, stepped, map pattern, vertical, horizontal & diagonal cracks.

01. Classification of Cracks Nature Wise:

Cracks in buildings can be broadly classified as structural and non-structural cracks.

Classification of Cracks

(a) Structural Cracks:

These cracks occur due to incorrect design, faulty construction or overloading and these may endanger the safety of a building. e.g. Extensive cracking of an RCC column of any structural element.

Structural Crack in Column
Courtesy - imgur

(b) Non-Structural Cracks:

These occur mostly due to internally induced stresses in building materials and do not endanger the safety of a building but may look unsightly, or may create an impression of faulty work or may give a feeling of instability. In some situations due to penetration of moisture through them, non-structural cracks may spoil the internal finishes thus adding to the cost of maintenance, or corrode the reinforcement, thereby adversely affecting the stability of the structure in long run.

Non-Structural Plaster Crack
Also Read: To Know about Types & Summary of Cracks in Reinforced Concrete Beams

02. Classification of Cracks Width Wise:

Cracks may appear in the structure either at the initial stage or with the time.  Some cracks are unavoidable in structure and subjected to numerous questions.

Cracks may appreciably vary in width from very thin hair crack barely visible to the naked eye (about 0.01mm in width) to gaping cracks 5mm or more in width.

Crack depending upon its width can be classified as follows:

(a) Thin Crack:

Less than 1 mm in width

Thin Cracks Appeared on Wall

(b) Medium Crack:

1 to 2 mm in width

Medium Cracks Appeared on Wall

(c) Wide Crack:

More than 2 mm in width.

Extensive wide crack appeared on Plastered Surface

(d) Crazing:

The occurrence of closely spaced fine cracks at the surface of a material is called crazing.

Extensive Crazing cracks appeared on Plastered wall

03. Classification of Cracks Shape-wise:

Cracks may appreciably vary in width from very thin hair crack barely visible to the naked eye to gaping crack. Vice versa cracks can be of uniform width throughout or may be narrow at one end gradually widening at the other.

Crack depending upon its shape can be classified as following:

(a) Straight:

Straight Crack on Wall
Courtesy – photobucket

(b) Toothed:

Toothed Cracks on wall
Courtesy – Slideplayer

(c) Stepped:

Stepped Crack on Wall

(d) Map Pattern or of Random Type:

Map Pattern Cracks or Random Type Cracks

(e) Vertical, Horizontal or Diagonal:

Horizontal, Vertical, Diagonal Cracks Pattern

Cracks may be only at the surface or may extend to more than one layer of materials such as paint, plaster, walls, or through cracks, etc…

Cracks due to different causes have varying characteristics and by the careful observations of these characteristics, one can diagnose the cause of cracking for adopting the appropriate remedial measures.
